2019 Pavan Pringles line

COMPLETE PAVAN STACKABLE POTATO CHIP / PRINGLES-STYLE

PRODUCTION LINE

Production Capacity: 450–500 kg/hour  |  Year of Manufacture: 2017–2019

Complete industrial stackable potato chip / Pringles-style production line incorporating Pavan processing and forming equipment, Heat and Control frying equipment, and downstream canister handling and packaging equipment.

The equipment was manufactured between approximately 2017 and 2019 and has seen relatively light production use, normally operating only two to three times per week for approximately one shift.

The complete line is presently dismantled and packed in wooden crates/pallets. A detailed packing list identifying the contents of each wooden case is available.

Production Process

The line provides a complete production system beginning with raw material handling and preparation, followed by mixing, dough preparation, rolling/forming, cutting, frying, oil discharge, seasoning/flavoring and transfer to the downstream canister handling and packaging equipment.

The principal Pavan processing section includes the buffer tank, gravimetric tank, mixer, metal detector conveyor, roller unit, cutter unit, scrap grinder, liquid tank unit and downstream product conveying systems.

The fryer is manufactured by Heat and Control, followed by Pavan oil discharge and flavoring conveyors.

Canister Handling & Packaging Section

Following processing and seasoning, the line includes chip filling and can-handling equipment, checkweighing and cooling, followed by canister seaming, printing and carton handling.

The packaging end includes Pavan chip filling and can-handling equipment, Pavan/Idecon checkweigher, Pavan cooling tunnel conveyor, Zilli & Bellini seamer, Hitachi canister printer, OMTeach carton filling conveyor and empty-can handling unit, and Clear Tech Italy depalletizer.

Complete Equipment Included

No.

Machine

Manufacturer

1

Tipping Station

SAT

2

Inclining Screw

SAT

3

Screener

SAT

4

Feeding Screw

SAT

5

Lindor Mixer

FPT / European

6

Floyer

FPT / European

7

Buffer Tank

Pavan

8

Gravimetric Tank

Pavan

9

Mixer

Pavan

10

Metal Detector Conveyor

Pavan

11

Roller Unit

Pavan

12

Cutter Unit

Pavan

13

Scrap Grinder

Pavan

14

Liquid Tank Unit

Pavan

15

Fryer

Heat and Control

16

Oil Discharge Conveyor

Pavan

17

Flavoring Conveyor

Pavan

18

Portioning System Conveyor

Pavan

19

Chips Filling Conveyor

Pavan

20

Load Can Handling Unit

Pavan

21

Checkweigher

Pavan / Idecon

22

Cooling Tunnel Conveyor

Pavan

23

Seamer

Zilli & Bellini

24

Canister Printer

Hitachi

25

Carton Filling Conveyor

OMTeach

26

Empty Can Handling Unit

OMTeach

27

Depalletizer

Clear Tech Italy

28

Thermic Fluid Heater

Thermax

29

Water Chiller

Himaliya

30

Dust Collector

SAT

31

Nitrogen Plant

Airro

Capacity & Utilities

Nominal production capacity

450–500 kg/hour finished stackable chips

Compressed air requirement

4 m³/min at 7.5 bar

RO water during production

250 liters/hour

Cleaning water requirement

6,000 liters

Frying oil operating temperature

185°C

Approximate oil consumption

250 kg/hour

Documentation & Current Condition

Mechanical drawings for the machinery are available, including drawings and interface information for the conveyors connecting the processing equipment to the filling/packaging section. Machine operating settings and available technical information can also be supplied.

The complete line is currently dismantled and packed in wooden crates, with a packing list identifying the machinery/components contained in each wooden case.

This is a complete high-capacity Pavan-based stackable potato chip production line, from ingredient preparation and forming through frying, seasoning, chip filling, canister handling, seaming, coding and carton handling, with a rated production capacity of approximately 450–500 kg/hour.
